Model | PD49NL |
Display panel | |
Panel | 48.5 inches LED backlit |
Active Area(mm) | 1074(W)×604.3(H) |
Product Size(mm) | 1077.5(W)×607.8(H)×113.8(D) |
Aspect Ratio | 16:9 |
Resolution | 1920×1080 |
Brightness | 450 cd/m2 |
Contrast Ratio | 1300:1 |
Viewing Angle | 178° |
Display Colors | 10Bit(D),1.06Billion colors |
Life Expectance | 60000 hours |
Ports | |
Interface | 3*Video、VGA、DVI、RGB/HV、HDMI、YPbPr、2*Audio、(Display Port、SDI alternative)、RS232 IN DB9(female)、 RS232 OUT DB9(male) 、RJ45 |
Media and Control | |
Video format | Avi, mp4, ts, trp, mkv, mov, mpg, dat, vob |
Audio format | Mp3, wma, m4a, aac |
Picture and text | Bmp, jpg, jpeg, png, txt |
Screen mode | Landscape, portrait, full screen, divided screen |
Play time control | Support |
Content input method | USB, LAN, WAN |
Other Parameters | |
Package Size(mm) | 1265(W)×840(H)×254(D) |
Bezel | 3.5mm(left:1.16; right: 2.34; up: 1.15; down: 2.35) |
Weight | Net:26KG Gross:32KG |
Power | 160W |
VESA | 300*600mm |
Mount | Landscape, Portrait |
RESET via watchdog | Support |
Time control | Support multi on and off task, automatically switch channel |
Power Supply | AC100-240V(50/60Hz) |
Working Temp.(°C) | 0〜50℃ |
Working Humidity(RH) | 10% 〜 80%RH |
Accessories | Remote control、Power cable |
