| Model | PD55N9 |
| Display panel | |
| Panel | 55 inches LED backlit |
| Active Area(mm) | 1209.9(W)×680.4(H) |
| Product Size(mm) | 1213.5(W)×684.3(H)×87(D） |
| Aspect Ratio | 16:9 |
| Resolution | 1920×1080 |
| Brightness | 500 cd/m2 |
| Contrast Ratio | 1400:1 LD OFF/100000:1 LD ON |
| Viewing Angle | ( R/L 89 (Min.), U/D 89 (Min.)) |
| Display Colors | 8bit, 16.7 M |
| Back light bulb Life | 50000 hours |
| Ports | |
| Audio and video ports | CVBS INx1, VGA INx1, DVI INx1, HDMI INx1 |
| Other ports | AC INx1, AC Switchx1, USB2.0x1, RS232/IR(RJ45) IN, RS232(RJ45)OUTx2 |
| Media and Control | |
| Video format | Avi, mp4, ts, trp, mkv, mov,mpg, dat, vob |
| Audio format | Mp3, wma, m4a, aac |
| Picture and text | Bmp, jpg, jpeg, png, txt |
| Play mode | full screen |
| Program transmission | USB |
| Other Parameters | |
| Package Size(mm） | 1380（W）×910（H）×265（D） |
| Weight | Net：29.1KG Gross：35KG |
| Power | 191W(MAX) |
| VESA(mm) | 400×600/300x600 |
| Screen hanging mode | Landscape、Portrait |
| Power Supply | AC~100-240V (50/60Hz ± 3 Hz ) |
| Working environment | 0〜40℃ 10% 〜 85%RH No condensation |
DRAWINGS
User Guide
.
 |
 |
 |
 |
 |
 |
 |
Quick start- QSG-MxxS4-PD&MxxST-MxxSD-V1.0.pdf |  |
| |
PD Series User Manual.pdf | |
