| Model | FMPF43H8 |
| Display panel | |
| Panel | 42.51 inches LED backlit |
| Active Area(mm) | 942.5（H）×529.416(W） |
| Product Size(mm) | 1034.5（H）×622.5（W）×64.7（D） |
| Aspect Ratio | 16:9 |
| Resolution | 1920×1080 |
| Brightness | 450 cd/m2 |
| Contrast Ratio | 5000:1 |
| Viewing Angle | 178° |
| Display Colors | 16.7M |
| Life Expectance | 60000 hours |
| Media player | |
| Android CPU | Dual Core ARM Cortex A9/1.6GHz |
| GPU | Quad Core ARM Mali-400 MP |
| Operation System | Android 4.2.2 |
| RAM | DDR3 1GB |
| NAND Flash | 8GB, Support TF card expansion |
| Network | WIFI, LAN, 3G (Optional) |
| Ports | |
| Interface | RJ45*1, USB*2, HDMI*1, VGA*1, Audio*1, TF socket, SIM card socket |
| Media and Control | |
| Video format | Avi, mp4, ts, trp, mkv, mov, mpg, dat, vob |
| Audio format | Mp3, wma, m4a, aac |
| Picture and text | Bmp, jpg, jpeg, png, txt |
| Screen mode | Landscape, portrait, full screen, divided screen |
| Play time control | Support |
| Content input method | USB, LAN, WAN |
| Other Parameters | |
| Package Size(mm） | 1156.5（H）×788（W）×183.6（D） |
| Weight | Net：21KG Gross：24KG |
| Power | 47W |
| Speaker | 2*2W, 4Ω |
| VESA | 200×500mm |
| Mount | Landscape, portrait |
| RESET via watchdog | Support |
| Time control | Support multi on and off task, automatically switch channel |
| Admin software | EzPoster / CDMS |
| Power Supply | AC100-240V(50/60Hz) |
| Working Temp.（°C） | 0〜40℃ |
| Working Humidity（RH） | 10% 〜 80%RH |
| Accessories | Remote control、Power cable |
DRAWINGS
User Guide
.
 |
L and PF Series User Manual.pdf |  |
|
Quick start- PF Series.pdf | |
 |
Ezposter.exe (Software) |  |
 |
Poster Editor (Software Tutoriar) |  |
