| MODEL | FMM65SA | ||||
| CPU | Dual Core ARM Cortex A9/1.6GHz | ||||
| GPU | Quad Core ARM Mali-400 MP | ||||
| Operation System | Android 4.2.2 | ||||
| RAM | DDR3 1GB | ||||
| NAND Flash | 8GB, Support TF card expansion | ||||
| Network | WIFI, LAN, 3G (Optional) | ||||
| Backlight Type | LED | ||||
| Screen Size | 65'' | ||||
| Display Size(mm) | 1428.48(H)×803.52(W) | ||||
| Resolution | 1920x1080 | ||||
| Brightness | 400 cd/㎡ | ||||
| Contrast Ratio | 5000:1 | ||||
| Viewing Angle | 178 | ||||
| Aspect Ratio | 16:9 | ||||
| Colors | 16.7M | ||||
| Life Time | 80000 Hours | ||||
| Materials Front Frame | Black Plastic | ||||
| Materials Housing | Black Metal | ||||
| Power Switch | Yes | ||||
| Speakers | 2W x2 ,4Ω | ||||
| Input Ports Video | VGA x1, HDMI x1 | ||||
| Input Ports Audio | Audio x 1 | ||||
| Input Ports Other | AC IN, USB | ||||
| Source Selection | VGA, HDMI, USB | ||||
| Language | English, Chinese (Simplified) | ||||
| Power Supply | AC 110-240V (50Hz-60Hz) | ||||
| Product Size(mm) | 1468.5(H)×843(W)×91.2(D) | ||||
| Working Temperature | 0℃ ~ 40℃ | ||||
| Storage Temperature | -10℃ ~ 60℃ (5℃ ~ 35℃ is recommended) | ||||
| Brightness Adjustment | Yes (Automatically adjust the brightness value according to surrounding environment) | ||||
| Supported Media Format | Video: MPEG1, MPEG2, MPEG4, H.264, WMV, MKV, TS, flv | ||||
| Picture: JPG, JPEG, BMP, PNG, GIF | |||||
| Audio: MP3 | |||||
| Timer On/Off | Supported by EzPoster and CDMS software | ||||
| Scrolling Text | |||||
| Multi Zone Display | |||||
| Supported Software | EzPoster: Support Standalone and Intranet control function | ||||
| CDMS: Support Internet control function | |||||
| Accessories | Remote Controller, CD, QSG | ||||
DRAWINGS
User Guide
.
 |
L and PF Series User Manual.pdf |  |
|
Quick start- PF Series.pdf | |
 |
Ezposter.exe (Software) |  |
 |
Poster Editor (Software Tutoriar) |  |
