| Model | FML75H10 |
| Display panel | |
| Panel | 75 inches LED |
| Active Area(mm) | 1648.7（H）×926.9(V） |
| Product Size(mm) | 2218(H)×1008(V)×93.6(Top) |
| Resolution | 3840*2160 |
| Panel Luminance | 530 cd/m2 |
| Contrast Ratio | 1200 |
| Viewing Angle | 178° |
| Backlight Life Time | 30000 hours |
| Media player | |
| CPU | RK 3288 Quad Core ARM Cortex A17 (Maximum 1.8GHz) |
| GPU | Quad Core ARMMail-764 |
| Operation System | Android 7.1 |
| RAM | DDR3 2GB |
| Media Transmission | USB, LAN, WAN |
| External Interface Portion | |
| AC input | AC switch*1 |
| Control Terminals |
EthernetRJ45*1, USB 2.0 *2, USB 3.0 *2 WiFi+ Bluebooth*1 |
| External ports |
HDMI 1.4 x1, VGA x1 |
| Media and Control | |
| Video format | MPEG1, MPEG2, MPEG4, WMV, MKV, AVI, TS, flv etc. |
| Audio format | *.mp3 etc |
| Picture and text | *.jpg, *.jpeg, *.gif, *.bmp, *.png, *.txt etc. |
| Installation Method | Floor Standing |
| Other Parameters | |
| Power Consumption | 300W |
| Power Supply | AC110-240V |
| Operating Temperature（°C） | 0〜40℃ |
| Operating Ambient Humidity（RH） | 10% 〜 80%RH |
| Accessories | Remote control、Power cable |
DRAWINGS
User Guide
.
 |
L and PF Series User Manual.pdf |  |
|
Quick start- PF Series.pdf | |
 |
Ezposter.exe (Software) |  |
 |
Poster Editor (Software Tutoriar) |  |
